: Features
Anti-Resonance, provides optimum torque and nulls mid-range instability
Motor auto-identification and parameter auto-configuration technology, offers optimum responses with different motors
Multi-Stepping allows a low resolution step input to produce a higher microstep output for smooth system performance
Microstep resolutions programmable, from full-step to 102,400 steps/rev
Supply voltage up to +72 VDC
Output current programmable, from 0.5A to 7.0A
Pulse input frequency up to 200 KHz
TTL compatible and optically isolated input
Automatic idle-current reduction
Suitable for 2-phase and 4-phase motors
Support PUL/DIR and CW/CCW modes
Over-voltage, over-current, phase-error protections
